The new generation of Mmmbop, our gravity led hardcore alloy 27.5’’ bike. The Mmmbop sharing the same geo as our steel Blue Pig, it’s slack, aggressive and built to embarrass your suspension riding peers. With hardtails being pushed harder and faster than ever before we have tweaked the trusted Ragley recipe for modern tastes. Our bikes have always been at the forefront of fun versatile hardcore hardtails and with a sprinkle of love with the same Ragley ingredients the fun has now been cranked up to 11.
Striking a balance between hardcore capabilities and all-day riding. The Mmmbop headtube has now been slackened to 63˚ and complimented with a shorter seattube to drop your saddle further, giving you even more commanding control when the trail gets steep, rowdy and airborne. An increased reach and 5mm lower BB gives you highspeed confidence and technical stability. Then for when you bang the saddle back up, the steeper 75˚ seat-angle puts you in a comfortable, balanced and efficient pedalling position.
More control and more fun like no other, with the updated geometry the Mmmbop is at home being piloted at an Enduro Race, epics into the mountains, sweet flat-out singletrack and smashing laps at your favourite trail centre or bike park.
The Mmmbop frame features all the modern no-nonsense fitting standards for easy serviceability. ISCG05 tabs, 44mm headtube, internal dropper routing, threaded BB and Boost 148x12mm rear wheel fitting. Engineered from custom butted Alloy 6061 tubing, offering a predictable lively ride, balanced with compliance and comfort.
Features:
- Alloy Frame
- Available in S, M, L and XL
- 27.5" Wheel
- Recommended Fork Travel: 150-160mm
GEOMETRY & SIZING
Small | Medium | Large | X-Large | |
---|---|---|---|---|
(A) Reach | 430mm | 455mm | 480mm | 505mm |
(B) Stack | 617mm | 626mm | 635mm | 644mm |
(C) Effective Top Tube Length | 595mm | 623mm | 650mm | 677mm |
(D) Seattube Length | 380mm | 410mm | 440mm | 470mm |
(E) Seattube Angle (Actual) | 75 | 75 | 75 | 75 |
(F) Headtube Length | 110mm | 120mm | 130mm | 140mm |
(G) Headtube Angle | 63 | 63 | 63 | 63 |
(H) Chainstay Length | 425mm | 425mm | 425mm | 425mm |
(I) Wheelbase | 1182mm | 1212mm | 1242mm | 1271mm |
(J) Bottom Bracket Drop | -50mm | -50mm | -50mm | -50mm |
(K) Stand Over Height | 659mm | 665mm | 691mm | 713mm |
(L) Fork Travel | 150mm – 160mm | 150mm – 160mm | 150mm – 160mm | 150mm – 160mm |
(M) Fork Offset | 37mm | 37mm | 37mm | 37mm |
(N) Axle to Crown | 542mm | 542mm (150mm Fork) | 542mm (150mm Fork) | 542mm (150mm Fork) |
FRAME SPECIFICATIONS
Material | 6061 Aluminium Alloy |
---|---|
Recommended Fork Travel | 150mm – 160mm |
Axle to Crown | 542mm (150mm Fork) |
Fork Offset | 37mm |
Wheels Size | 27.5'' |
Max Tyre Size | 2.6'' |
Headtube | ZS44/28.6 | ZS56/40 |
Seatpost | 31.6mm |
Seat Clamp | 34.9mm |
BB | 73mm BSA |
Rear Hub | 12mm x 148mm Boost |
Rear Axle | 175mm x M12*P1.5 |
Chain Guide | ISCG 05 Tabs |
Brake Mount | Post 160mm |
Protection | Chain Stay Protector |
